A5505 Stainless Steel Continuous Hinge - Full Concealed - 12 Gauge

A5505 Stainless Steel Continuous Hinge - Full Concealed - 12 Gauge

$0.00
  • Full Concealed, heavy duty
  • 12 gauge 304 grade stainless steel material
  • 16 gauge 304 stainless steel material for edge guard angle bracket
  • No door inset, flush mount
  • Welded hospital tip provided standard
  • Door edge guards on both faces of the door
  • 48" door width maximum
  • 900 lbs. door weight maximum
  • Fasteners: 12-24 x 1/2" undercut machine screws, stainless steel
  • Lengths: 78-3/4", 83-1/8". 85", 95" and 118-3/4"
  • Fire Rating - tested and certified by UL® (U.S.A. and Canada) on 4'0" x 10'0" fire rated doors, based on the following
    • 20 minutes - wood doors
    • 90 minutes hollow metal and composite wood fire doors
    • 3 hours - hollow metal doo
  • "TW" - Concealed Electrical Thru-Wire
  • "EZ" - EZ Connect Molex Plug-in Connectors for installation ease
  • "M" - Moveable Electrical Access Prep
  • "PT" - Cut-out Prep for Power Transfer
  • "AMS" - Adjustable Monitoring Switch
  • "CT"- Concealed Electrical Thru-Wire and Monitor Switch
  • "CUT" - Cut to Custom Length
  • "SPLICE" - Spliced Hinge
  • "DD" - Dutch Door Prep
  • "STUD" - Security Studs
  • "SEC" - Fasteners
  • "SL" - Sheared Leaf
  • "ADB" - Cut for Automatic Door Bottom
  • "CUSTOM HOLE" - Custom hole locations
  • "NO HOLE"
  • "CUSTOM FINISH"
